A Vivaldi antenna or Vivaldi aerial[1] or tapered slot antenna[2] is a co-planar broadband-antenna, which can be made from a solid piece of sheet metal, a printed circuit board, or from a dielectric plate metalized on one or both sides.

Get this from a library! RF coaxial slot radiators: modeling, measurements and applications. Kok Yeow You.

  • The motivation behind this study is specifying the proper arrangement of periodic air slots within the multi-slot coaxial antenna with 50-Ω. The S 11-parameter Analysis of Multi-slot Coaxial Antenna with Periodic Slots. Authors; Authors and affiliations. Munoz-Rojas, P.A. (ed.) Computational Modeling, Optimization and Manufacturing.
  • Vivaldi antennas are simple planar antennas that are very broadband. The polarization is linear, and the basic antenna structure is shown in Figure 1: Figure 1. Basic Geometry of a Vivaldi Antenna. In Figure 1, we have the antenna feed connecting two symmetric sides of a planar metallic antenna.
Pattern of a Vivaldi antenna, made from double-sided printed circuit board material

The feeding line excites an open space via a microstrip line or coaxial cable, and may be terminated with a sector-shaped area or a direct coaxial connection. From the open space area the energy reaches an exponentially tapered pattern via a symmetrical slot line.

A one-piece sheet metal vivaldi antenna undergoing testing in an anechoic chamber

Vivaldi antennas can be made for linear polarized waves or – using two devices arranged in orthogonal direction – for transmitting / receiving both polarization orientations.

If fed with 90-degree phase-shifted signals, orthogonal devices can transmit/receive circular-oriented electromagnetic waves.

Vivaldi antennas are useful for any frequency, as all antennas are scalable in size for use at any frequency. Printed circuit technology makes this type antenna cost effective at microwave frequencies exceeding 1 GHz.

This inexpensive Vivaldi antenna is etched upon a printed circuit board and fed with a soldered-on coaxial cable and SMA connector.

Advantages of Vivaldi antennas are their broadband characteristics (suitable for ultra-wideband signals [3]), their easy manufacturing process using common methods for PCB production, and their easy impedance matching to the feeding line using microstrip line modeling methods.
